Extend the Server to the Service Position
Note - You can replace the drives, DVD drive, and power supplies without extending the server
into the service position.
1.
Verify that no cables will be damaged or will interfere when the server is
extended.
Although the CMA that is supplied with the server is hinged to accommodate extending the
server, you should ensure that all cables and cords are capable of extending.
2.
From the front of the server, release the two slide release latches.
Squeeze the green slide release latches to release the slide rails.
3.
While squeezing the slide release latches, slowly pull the server forward until the
slide rails latch.
4.
Release the CMA.
See “Release the CMA” on page 59.
58 SPARC T7-2 Server Service Manual • July 2019
