Space Requirements
TABLE 1
Oracle Server X5-2 Physical Specifications
Dimension Server Specification Measurements
Width Server chassis 43.65 cm (17.19 inches)
Depth Maximum overall 73.7 cm (29 inches)
Height 1-rack unit (1U) nominal 4.26 cm (1.68 inches)
Weight Fully populated server 18 kg (40 lbs)
Related Information
■
“Space Requirements” on page 16
■
“Rack Requirements” on page 40
Space Requirements
The Oracle Server X5-2 is a 1 rack unit (1U) server. For physical dimensions, see “Server
Physical Specifications” on page 15.
The server can be installed into a four-post rack cabinet that conforms to ANSI/EIA 310-D-
1992 or IEC 60927 standards, such as Oracle's Sun Rack II. All Oracle racks have the same
space requirements. The specifications for Oracle's Sun Rack II are listed in the following table.
TABLE 2
Sun Rack II Models 1242 and 1042 Specifications
Requirement Specification
Usable rack units 42
Height 199.8 cm (78.66 inches)
Width (with side panels) 60 cm (23.62 inches)
Depth Model 1242
†
Depth Model 1042
†
120 cm (47.24 inches)
105.8 cm (41.66 inches)
Weight Model 1242
Weight Model 1042
150.6 kg (332 lbs)
123.4 kg (272 lbs)
Maximum dynamic load 1005 kg (2215 lbs)
†
Depth is measured from front door handle to rear door handle.
The minimum ceiling height for the cabinet is 230 cm (90 inches), measured from the true floor
or raised floor, whichever is higher. An additional 91.4 cm (36 inches) is for top clearance. The
space above the cabinet and its surroundings must not restrict the movement of cool air between
16 Oracle Server X5-2 Installation Guide • January 2021
