Space Requirements
the air conditioner and the cabinet, or the movement of hot air coming out of the top of the
cabinet.
The following sections provide additional space requirements:
■
“Receiving and Unpacking Guidelines” on page 17
■
“Maintenance Space Guidelines” on page 17
Receiving and Unpacking Guidelines
The following table lists the dimensions and weights for the Oracle Server X5-2 shipping
carton.
TABLE 3
Shipping Carton Specifications
Requirement Specification
Shipping carton height 26.0 cm (10.24 inches)
Shipping carton width 60.65 cm (23.88 inches)
Shipping carton length 99.0 cm (38.98 inches)
Shipping carton weight 5.65 kg (12.46 lbs)
When the server is unloaded at your site, leave the server in its shipping cartons until it arrives
in its installation location. Use a separate area to remove the packaging material to reduce
particle contamination before entering the data center. Ensure that there are clear pathways and
enough clearance for moving the server from the unpacking area to the installation location.
The entire access route to the installation site should be free of raised-pattern flooring that can
cause vibration.
Maintenance Space Guidelines
The maintenance area for the rackmounted Oracle Server X5-2 must have the required access
space. The following table lists the maintenance access requirements for the server when it is
installed in a rack.
TABLE 4
Maintenance Access Requirements
Location Maintenance Access Requirement
Rear of the server 91.4 cm (36 inches)
Area above the rack 91.4 cm (36 inches)
Preparing for Server Installation 17
