Back Panel Status Indicators, Connectors, Drives, and PCIe Slots
Call Out Description
1 Product Serial Number (PSN) label and Radio Frequency Identification (RFID) tag
2 Locator LED/button: white
3 USB 2.0 connectors (2)
4 SP OK LED: green
5 Service Required LED: amber
6 Power/OK LED: green
7 Power button
8 Service Required LED: Top: Fan Module (amber)
9 Service Required LED: Rear: Power Supply (amber)
10 Service Required LED: Overtemp Icon: System Over Temperature Warning (amber)
11 Storage drive 0
12 Storage drive 1
13 Storage drive 2 (Optional NVM-Express SSD)
14 Storage drive 3 (Optional NVM-Express SSD)
15 Storage drive 4 (Optional NVM-Express SSD)
16 Storage drive 5 (Optional NVM-Express SSD)
17 Storage drive 6
18 Storage drive 7
19 Optional SATA DVD Drive
Related Information
■
“Back Panel Status Indicators, Connectors, Drives, and PCIe Slots” on page 30
Back Panel Status Indicators, Connectors, Drives, and PCIe
Slots
The following figure shows the Oracle Server X5-2 back panel and the location of status
indicators (LEDs), connectors, and PCIe slots.
For information about how to interpret the status indicators (LEDs), refer to the Oracle Server
X5-2 Service Manual.
30 Oracle Server X5-2 Installation Guide • January 2021

Oracle X5-2 Specifications

General

Number of Processors	2
Cores per Processor	Up to 18
Form Factor	2U Rackmount
Processor	Intel Xeon E5-2600 v3
Memory	Up to 768 GB DDR4
Power Supply	1200W
Operating System	Oracle Linux, Oracle Solaris
Network	4 x 10Gb Ethernet ports
