Mark the Rackmount Location
3.
Verify that the rear locating pin has engaged the mounting bracket clip.
4.
Repeat Step 1 through Step 3 to install the remaining mounting bracket on the
other side of the server.
Related Information
■
“Mark the Rackmount Location” on page 45
■
“Attach Tool-less Slide-Rail Assemblies” on page 49
Mark the Rackmount Location
Identify the location in the rack where you want to place the server. The server requires one
rack unit (1U).
Use the rackmount installation card to identify the correct mounting holes for the slide-rails.
Note - Load the rack from bottom to top.
1.
Ensure that there is at least 1 rack unit (1U) of vertical space in the rack cabinet
to install the server.
See “Rack Requirements” on page 40.
2.
Place the rackmount installation card against the front rails.
Installing the Server Into a Rack 45
