Remove the Cable Management Arm
Related Information
■
“Remove the Cable Management Arm” on page 70
Remove the Cable Management Arm
Follow this procedure to remove the cable management arm (CMA).
Before you begin this procedure, refer to the illustrations in Step 1 to identify CMA connectors
A, B, C, and D. You should disconnect the CMA connectors in the reverse order in which you
installed them, that is, disconnect connector D first, then C, then B, and finally A.
Throughout this procedure, once you disconnect any of the CMA's four connectors, do not
allow the CMA to hang under its own weight.
Note - References to “left” or “right” in this procedure assume that you are facing the back of
the equipment rack.
1.
To prevent the rack from tipping forward when the server is extended, extend all
rack anti-tilt devices.
Caution - To reduce the risk of personal injury, stabilize the rack cabinet and extend all anti-tilt
devices before extending the server from the rack.
For instructions for stabilizing the rack, see “Stabilize the Rack for Installation” on page 43.
2.
To make it easier to remove the CMA, extend the server approximately 13 cm (5
inches) out of the front of the rack.
3.
To remove the cables from the CMA:
a.
Disconnect all cables from the rear of the server.
b.
If applicable, remove any additional Velcro straps that were installed to
bundle the cables.
c.
Unwrap the six Velcro straps that are securing the cables.
d.
Open the three cable covers to the fully opened position.
e.
Remove the cables from the CMA and set them aside.
70 Oracle Server X5-2 Installation Guide • January 2021
