Oracle X5-2 - Front Panel Status Indicators, Connectors, and Drives

Front Panel Status Indicators, Connectors, and Drives
Feature Description
■ Oracle VM (preinstall option)
■ RedHat Enterprise Linux
■ Microsoft Windows Server 2012
■ Microsoft Windows Server 2012 R2
■ VMware ESXi
■ SUSE Linux Enterprise Server
For a complete list of supported OS versions for your server, refer to the Oracle Server
X5-2 Product Notes at: https://www.oracle.com/goto/x5-2/docs
Related Information
■
“Front Panel Status Indicators, Connectors, and Drives” on page 29
■
“Back Panel Status Indicators, Connectors, Drives, and PCIe Slots” on page 30
Front Panel Status Indicators, Connectors, and Drives
The following figure shows the status indicators (LEDs), connectors, and drives located on the
front panel of a Oracle Server X5-2 configured with eight 2.5-inch storage drives and a SATA
DVD drive.
For information about how to interpret the status indicators (LEDs), refer to the Oracle Server
X5-2 Service Manual.
Server Features and Components 29
