Attach Tool-less Slide-Rail Assemblies

Orient the slide-rail assembly so that the ball-bearing track is forward and locked

in place.

Number Description

1 Slide-rail

2 Ball-bearing track

3 Locking mechanism

50 Oracle Server X5-2 Installation Guide • January 2021
