Oracle X5-2 User Manual

Install the Cable Management Arm
Number Description
2 Front slide bar
3 Velcro straps (6)
4 Connector B
5 Connector C
6 Connector D
7 Slide-rail latching bracket
(used with connector D)
8 Rear slide bar
9 Oracle Server X5-2 cable
covers
10 Oracle Server X5-2L cable
covers
2.
Ensure that the correct cable covers for your server are installed on the CMA.
■
The Oracle Server X5-2 (1U system) uses the flat cable covers.
■
The Oracle Server X5-2L (2U system) uses the round cable covers.
Note - The CMA ships with three, flat cable covers installed. If you are going to install the
CMA on a Oracle Server X5-2L, you need to remove the flat cable covers and install the round
cable covers.
3.
If you are installing the CMA on an Oracle Server X5-2L, remove the flat cable
covers and install the round cable covers; otherwise proceed to the next step.
To remove the flat cable covers and install the round cable covers, perform these steps:
a.
Lift up on the cable cover handle (the handle is colored green) and open
it 180 degrees to the horizontal position as shown in the following figure
[frames 1 and 2].
Installing the Server Into a Rack 59

Oracle X5-2 Specifications

General

Number of Processors	2
Cores per Processor	Up to 18
Form Factor	2U Rackmount
Processor	Intel Xeon E5-2600 v3
Memory	Up to 768 GB DDR4
Power Supply	1200W
Operating System	Oracle Linux, Oracle Solaris
Network	4 x 10Gb Ethernet ports
