Oracle X5-2 User Manual

Install the Cable Management Arm
b.
Gently tug on the right side of the front slide bar to verify that connector B is
properly seated.
Number Description
1 Connector B tab
2 Right slide-rail front slot
9.
To install the CMA's connector C into the right slide-rail:
Installing the Server Into a Rack 63

Oracle X5-2 Specifications

General

Number of Processors	2
Cores per Processor	Up to 18
Form Factor	2U Rackmount
Processor	Intel Xeon E5-2600 v3
Memory	Up to 768 GB DDR4
Power Supply	1200W
Operating System	Oracle Linux, Oracle Solaris
Network	4 x 10Gb Ethernet ports
