Oracle X5-2 User Manual

Remove the Cable Management Arm
a.
Place your right arm under the CMA to support it and grasp the rear end of
connector B with your right hand.
b.
Use your left thumb to pull the connector B release lever to the left away
from the right slide-rail (callout 1) and use your right hand to pull the
connector out of the slide-rail [frames 1 and 2].
Number Description
1 Connector B release lever
7.
To disconnect connector A:
a.
Place your left arm under the CMA to support it and grasp the rear end of
connector A with your left hand.
Installing the Server Into a Rack 73

Oracle X5-2 Specifications

General

Number of Processors	2
Cores per Processor	Up to 18
Form Factor	2U Rackmount
Processor	Intel Xeon E5-2600 v3
Memory	Up to 768 GB DDR4
Power Supply	1200W
Operating System	Oracle Linux, Oracle Solaris
Network	4 x 10Gb Ethernet ports
