Orion FLEX Series User Manual

Orion Machine Manual
Revision 1.1 AG 360 RoboWrapper
28 June 2017 Troubleshooting
Page 4-5
Safety Bumper
There is a safety bumper on the front of the machine that stops the machine when it hits
and obstacle during operation. An alarm message will display on the HMI if the bumper
stops the machine. Check that the bumper switch is operating properly prior to running for
the day.
Transmission Engage/ Disengage
There is a transmission engage/ disengage lever located at the back right bottom corner of
the machine. An alarm message will display on the HMI if the transmission is disengaged.
The transmission must be engaged to allow operation. See “Transporting the AG 360” on
Page 3-3.
Figure 4 - 9
Safety Bumper
Figure 4 - 10
Transmission Engage/
Disengage Lever
