Orion FLEX Series User Manual

Machine Manual Orion
AG 360 RoboWrapper Revision 1.1
System Operation 28 June 2017
Page 3-10
Universal Go-To Buttons
The buttons in the chart below are found throughout most HMI screens. The buttons allow
the user to easily navigate back to any of the screens.
Table 3-1. The Universal Go-To Button Descriptions
STATE 1 DESCRIPTION
Press this button to go to the Run Screen. The icon will illuminate in green when the
screen is currently active.
Press this button to go to the Recipes Screen. The icon will illuminate in green when
the screen is currently active.
Press this button to go to the Menu Screen. The icon will illuminate in green when
the screen is currently active.
Press this button to go to the Machine Settings Screen. The icon will illuminate in
green when the screen is currently active.
