Orion Machine Manual
Revision 1.1 AG 360 RoboWrapper
28 June 2017 System Operation
Page 3-7
7. Verify the film cling is inward on the load. If not, the film spool will need to be
flipped.
8. When the film feeding is completed, release the E-stop.
Note:
Ensure there is a clear path of 52” around all sides of the load prior to
wrapping.
9. Press the Reset button. Film will not feed until control power is present.
10. Peel off the first few winds of the film (multistretch will run due to displacement of
the dancer roller) and fix the film end onto the load.
11. The film tail should be connected to the load around a corner to ensure the wrap stays
on the load.
12. The system is now ready to begin the first wrapping cycle.
13. Press the Start button to start wrapping the load.
14. Stand clear of the machine while in operation.
Figure 3 - 10
Film Cling Diagram
FILM
FILM
Cling Outside
Cling Inside
To Next Page
