Orion FLEX Series User Manual

Orion Machine Manual
Revision 1.1 AG 360 RoboWrapper
28 June 2017 System Operation
Page 3-21
Tension Sensor Calibration Screen
This is the Tension Sensor Calibration screen. This screen allows the user to calibrate the
tension sensor.
Figure 3 - 22
The Tension Sensor
Calibration Screen
Table 3-9. The Tension Sensor Calibration Screen Button Descriptions
STATE 1 DESCRIPTION
START CALIBRATION
Press this button to calibrate the Tension Sensor. First, press the E-stop button.
Next, press the tensioner all the way in and out three times. Wait for the calibration
done message to display.
