Orion FLEX Series User Manual

Orion Machine Manual
Revision 1.1 AG 360 RoboWrapper
28 June 2017 System Operation
Page 3-15
Recipe Select Screen
This is the Recipe screen. This screens allows the user to select different wrap recipes
quickly. Changes made to a recipe are saved to the active recipe.
Figure 3 - 17
The Recipe Screen
Table 3-4. The Recipe Screen Button Descriptions
STATE 1 DESCRIPTION STATE 2
SELECT RECIPE #
Press a recipe button to choose between the different
recipe wrap settings. Changes made to a recipe are
saved to the active recipe. If you attempt to change to
a different recipe while the wrapper is loading, then
the new recipe you select will display as loading and
will only change once the current wrap cycle is com-
plete.
RUNNING RECIPE #
LOADING RECIPE #
RECIPE SETTINGS Press this button to go to the Recipe Settings screen.
