Revision 1.1 AG 360 RoboWrapper
28 June 2017 Maintenance
Page 5-3
Charging and Indicator Connectors on Door
If the batteries are not charging, an additional check would be the connector on the back of
the door panel. Ensure the connections are properly plugged in and not loose.
HMI Back Panel
Check the connections on the back of the HMI if the screen won’t power up.
Figure 5 - 5
Charging Connector
and Indicator
Connections
Figure 5 - 6
Back of HMI
