Orion FLEX Series - Diagnostics Screen; The Diagnostics Screen

Machine Manual Orion
AG 360 RoboWrapper Revision 1.1
System Operation 28 June 2017
Page 3-22
Diagnostics Screen
This is the Diagnostics screen. This screen allows navigation to each of the Diagnostic
Screens.
Figure 3 - 23
The Diagnostics
Screen
Table 3-10. The Diagnostics Screen Button Descriptions
STATE 1 DESCRIPTION
INPUTS Press this button to go to the Inputs Screen.
MANUAL Press this button to display the machine manual.
FAULT HISTORY Press this button to go to the Fault History Screen.
HMI Press this button to go to the HMI adjustment Screen.
BATTERY SETTINGS Press this button to go to the Battery Settings Screen.
