MercuryiTC
©2014 Oxford Instruments Omicron NanoScience. All rights reserved.
Page 118
H1 Sensor 1 used for heater control.
H2 Sensor 2 used for heater control.
H3 Sensor 3 used for heater control.
8.4.3.5 Mnnn command - Set Maximum Heater Volts Limit
The MAXIMUM HEATER command sets the maximum heater voltage that the iTC may deliver,
either under automatic control or in response to an Onnn command. The parameter nnn can
take any decimal value within the corresponding range (which depends on the configuration).
So, both M12 and M12.345 are valid.
8.4.3.6 Onnn command - Set % Output Volts
Sets the required heater output, when in MANUAL mode. The parameter nnn is expressed as a
percentage of the maximum heater voltage (set by the Mnnn command) with a resolution of
0.1% (i.e. the range of nnn is 0 to 99.9).
8.4.3.7 Tnnn command - Set Desired Temperature
The TEMPERATURE command sets a set point temperature. The parameter is the required
temperature, sent as a signed decimal number, The parameter nnn can take any decimal value
within the corresponding range (which depends on the configuration). So, both T12 and
T12.345 are valid.
8.4.4 Legacy system commands
! command - Set ISOBUS Address
This is equivalent to setting the ISOBUS address using the RS232 Settings page (section
7.1.1).
