MercuryiTC
©2014 Oxford Instruments Omicron NanoScience. All rights reserved.
Page 23
3 GETTING STARTED
Ensure that you have read and understood the information in Chapter 1 before installing or
operating this equipment.
3.1 Checking the electrical supply
CHECK THE SUPPLY VOLTAGE
Check that the voltage supplied to the equipment is within the
specified range. Operating the equipment with an incorrect voltage
may cause permanent damage.
CONTRÔLER LA TENSION D'ALIMENTATION
Contrôler que la tension fournie à l'équipement est comprise dans
les limites spécifiées. Exploiter l'équipement avec une tension
incorrecte peut l'endommager de manière permanente.
The MercuryiTC automatically configures itself to match the supplied electrical power supply. If
the voltage and frequency are within the specified ranges (see section 17.2), no user
intervention is required.
3.2 Mounting the equipment
The equipment is housed inside a 19 inch, 2U rack-mountable enclosure. The enclosure can
either be placed on a bench or a table, or fitted within a suitable rack enclosure. Ensure there is
sufficient access at the rear for the electrical connections.
EQUIPMENT VENTILATION
If the MercuryiTC is to be rack mounted, to ensure an adequate
airflow around the iTC it is important that the back of the rack is
open and the rack is not placed less than 30 cm from a back wall.
VENTILATION D’EQUIPEMENT
Lorsque le Mercury est monté en rack, s'assurer que le rack est
ouvert à l'arrière et se trouve au minimum à 30 cm du mur afin de
garantir une circulation d'air suffisante.
