MercuryiTC
©2014 Oxford Instruments Omicron NanoScience. All rights reserved.
Page 161
17 TECHNICAL SPECIFICATIONS
This chapter lists the technical specifications of the MercuryiTC.
17.1 Physical specification
Item Specification
Width 426 mm
Depth 272 mm
Height 131 mm
Weight 6.5 kg
17.2 Electrical power supply
Item Specification
Mains supply voltage 100 VAC to 240 VAC
Mains supply frequency 50 Hz to 60 Hz
Maximum supply power 650 W
Compliance Standard CE,
C
ETL
US
(UL and CSA recognised standard)
Maximum mains voltage fluctuation ±10% of nominal voltage
Category II transient overvoltages can typically be present on the mains supply.
17.3 Sensor inputs
Item Specification
Basic iTC – single sensor input Upgradeable to 9 sensor inputs
NTC resistance range 5 ohms to 200 kohms
Constant voltage Typically <10 mV
PTC resistance range 5 ohms to 3 kohms
Constant current
0.1 to 1000 µA
Sensors to be connected with four wires (pins 1, 3, 4 and 5) of 9-way D-connector on iTC.
Pin 2 is sense shield.
Sensor ADC resolution 24 bit
Resistance-sensor excitation modes Unipolar or bipolar
Sensor sampling rate Typically 1 Hz. Maximum 10 Hz.
