V–19
● Outdoor Unit Data 5 Seconds Earlier (A.1 to A.i)
Data
code
Data name Unit
Display
examples
Remarks
A.1 Engine revolution setting min
-1

2,200 min
-1
A.2 Engine revolutions min
-1

2,200 min
-1
A.3 Compressor inlet pressure MPa

0.10 MPa
A.4 Compressor outlet pressure MPa

1.00 MPa
A.5 Compressor inlet temperature °C

35.0°C
A.6 Compressor outlet temperature °C

110.0°C
A.7 Outdoor unit fan 1 %

100%
A.8 Outdoor unit fan revolutions 1 min
-1

650 min
-1
A.9 Coolant pump revolutions min
-1

3,700 min
-1
A.A Throttle Step

100 steps
A.b Fuel gas regulating valve Step

330 steps
A.C Liquid valve Step

220 steps
A.d Bypass valve Step

100 steps
A.E Outdoor unit solenoid valve 1 Step

480 steps
A.F Outdoor unit solenoid valve 2 Step

480 steps
A.G Revolution speed variable (F_rpm)

0.2
A.H
A.i Engine ignition time Degree

10 degrees
● Outdoor Unit Data 10 Seconds Earlier (b.1 to b.i)
Data
code
Data name Unit
Display
examples
Remarks
b.1 Engine revolution setting min
-1

~
Same as the outdoor unit data 5 seconds earlier
b.i Engine ignition time Degree

● Outdoor Unit Data 15 Seconds Earlier (C.1 to C.i)
Data
code
Data name Unit
Display
examples
Remarks
C.1 Engine revolution setting min
-1

~
Same as the outdoor unit data 5 seconds earlier
C.i Engine ignition time Degree

Note: The data during normal display will be displayed with the same digits, but there are cases in which
accuracy is deteriorated.
