V–32

Indoor Unit Setting: No. 6 (Level 0) <

>
Key operation is used for indoor unit settings (operation impossible when connecting the water heat exchanger).
1) Indoor unit setting display (Level 0)
Shows menu selected indoor unit status display.

2) Outdoor unit setting item select operation (Level 1)
Pressing the SET (S007) key in the indoor unit setting display mode activates the following display.
(Occurs only upon completion of initial communication)
Example :

(Example: Indoor No. 1 unit, data code 1, with gas tube valve)
Operating the UP (S005) and DOWN (S006) keys in this mode makes it possible to select setting categories.
Pressing the HOME (S004) key or conducting no operations for 10 minutes activates a return to the HOME
display.
3) Outdoor unit setting operation (Level 2)
Setting start operation method : Press the SET (S007) key for one second in the setting data code select
mode.
This activates the forced setting in progress display. (TEST/WARNING
LED light)
Setting change operation method : After entering the setting start operation mode, operating the UP (S005)
and DOWN (S006) keys make it possible to change the setting details
of the selected setting categories.
Setting confi rm operation method : After entering the setting start operation or setting change operation
completed, press the SET (S007) key for one second. This cancels the
forced setting in progress display, returning to indoor unit setting item
select operation. (TEST/WARNING LED off)
Setting cancel operation method : “Pushing the HOME (S004) key for 1 second before setting confi rm
operation returns operation to normal.”
(Setting details will not be cancelled when pushing the HOME (S004) key for more than 1 second during
indoor unit setting item select operation.)
4) Outdoor unit setting list
Data code Data Remarks
←Down Up→
1 Indoor unit setting 1
(indoor unit 1)
0/1 (Gas tube valve present/absent)
2 Indoor unit setting 2 0= Lowest priority to 4= Highest priority
3 Indoor unit setting 3 0/1 (Normal/Drain pump intermittent control)
4 Indoor unit setting 4 0/1 (Normal/Drain pump continuous control)
5 Indoor unit setting 5 0/1 (Normal/No cool air prevention control with heater thermostat-off)
6 Indoor unit setting 6 0/1 (Normal/No air speed control with heater thermostat-off)
7 Indoor unit setting 7 0/1 (Normal/No heater high-pressure avoidance control)
8 Indoor unit setting 8 0/1 (Normal/Heater stop indoor frost prevention control)
9 Indoor unit setting 9 0/1 (Normal/No refrigerant discharge control with heater thermostat-off)
A Indoor unit setting A 0/1 (Normal/Air speed lower limit with heater thermostat-on LL)
B Indoor unit setting B 0 to 8 (Cooling indoor fan odor compensation)
C Indoor unit setting C 0/1 (Normal/Air speed select when dry thermostat off LL ↔ stop)
D Indoor unit setting D 0 to 120 (Heating thermostat on upper limit:0,4,…480step)
E Indoor unit setting E 0 to 120 (Heating thermostat on lower limit:0,4,…480step)
F Indoor unit setting F 0 to 120 (Initial heating discharge:0,4,…480step)
G Indoor unit setting G 0 to 120 (Initial cooling thermostat on:0,4,…480step)
H Indoor unit setting H 0 to 120 (Heating high pressure avoidance:0,4,…480step)
I Indoor unit setting I 0 to 120 (Cooling thermostat on lower limit:0,4,…480step)
J Indoor unit setting J 0 to 120 (Heating thermostat off:0,4,…480step)
K Indoor unit setting K 0 to 120 (Cooling thermostat off oil recovery:0,4,…480step)
L Indoor unit setting L -35 to 92 (Cooling discharge temperature:0= depending on model type,
-35 to 92°C)
N Indoor unit setting N -35 to 92 (Heating discharge temperature:0= depending on model type,
-35 to 92°C)
