Panasonic 2WAY Multi - Page 91

IV–78
● 2-4
The coolant temperature setting is performed with SW2 and SW3 (green rotary switches).
Set SW2 at tens place and SW3 at ones place. The set temperature range is between +5°C and +15°C.
(Example: If SW2 is set at “0” and SW3 at “7”, the set temperature is “+7°C”.)
● 3-2
Position 3 on SW1 (3P dip switch) selects whether the temperature is to be set at a positive value or a negative
value.
Set Temperature SW1 Position 3
Negative (-) ON (knob at the top)
Positive (+) OFF (knob at the bottom)
Set SW2 at tens place and SW3 at ones place. The set temperature range is between -15°C and +5°C.
(Example: If SW1 position 3 is set at “ON”, SW at “0” and SW3 at “5”, the set temperature is “-5”.)
A setting between +5°C and +15°C can be set. In this event, set position 1 on SW8 (4P dip switch) to OFF (with
the knob at the bottom).
