IEC 60870 functions of the FP Web-Server
166 FP Web-Server V2.810 EN
 Multipoint with C-Net adapter
 Line parameter: half duplex RS485
 baud rate: format as RS232C (up to 19200bps)
 terminator: see manual of the adapter used
 C-Net adapter: AFP8536 is tested only
 no handshake is used
 RS232C cable from AFP8536 to RTI / RTU:
 AFP8536: 9-pin RS232C female
 RTI/RTU: 9-pin male IBM PC standard
AFP8536
PC
pin 2 ---pin 2
pin 3 ---pin 3
pin 7 ---pin 5
bridge:
pin 4 -pin 5
bridge:
pin 7 -pin 8
bridge:
pin 8 -pin 9
bridge:
pin 4 -pin 6
 Settings for RTI (Lian98 from Ver 1.0.1.2 onwards):
 baud rate 19200bps
 data bits, parity, stop bits set to same values as RTU
 timeout 200ms minimum
 modem: full duplex
 transmission: unbalanced
 Settings for RTU (IEC Communicator):
 baud rate 1200bps
 data bits, parity, stop bits set to same values as RTI
 handshake: NONE
 mode: RS232C
 Optimized IEC60870 multipoint modem handling
The optional RTS delay timing for optimized multipoint modem RTS control
can be determined in the MEW60870.INI file.
 MP_WAIT=50: Wait time in ms; Wait this long before activating RTS
(between the data packets)
