Panasonic KX-TDA50

ESF Frame Sequence
Selects the values for C-bit and D-
bit. To enable this setting,
Frame Sequence on this screen should be
set to ESF.
Default
C=A, D=B
Value Range
C=A, D=B; C=0, D=0; C=0, D=1; C=1, D=0; C=1, D=1
Maintenance Console Location
3.16 [1-1] Slot—Card Property - T1 type (KX-TDA100/KX-TDA200/KX-TDA600 only)
Programming Manual References
None
Feature Manual References
None
LIU Send Option
Selects the transmitting level (Transmit Pulse Amplitude) of LIU.
Default
Mode-1
Value Range
Mode-1–Mode
-8
Maintenance Console Location
3.16 [1-1] Slot—Card Property - T1 type (KX-TDA100/KX-TDA200/KX-TDA600 only)
Programming Manual References
None
Feature Manual References
None
LIU Receive Option
Selects the receiving level (Receive Equalization) of LIU.
Default
Automatic
162 PC Programming Manual Document Version 2010-11
3.16 [1-1] Slot—Card Property - T1 type (KX-TDA100/KX-TDA200/KX-TDA600 only)
