Name on SD Memory Card Corresponding Card
DLIIPGW2 IP-GW4 (KX-TDA0484)
DLIIPGW3 IP-GW16
DLIPRI23 PRI23
DLIIPEXT IP-EXT16
To transfer files to the SD memory card
1. From the Utility menu, select File Transfer PC to PBX (SD Card).
The dialog box will be displayed.
2. Select the file to upload.
A window showing the upload progress will be displayed.
While transferring files to the SD memory card, the PBX automatically renames them according to the
header information.
A message will be displayed when the transfer is complete.
3. Click OK.
2.6.3 Utility—File Transfer PBX (SD Card) to PC
Copies system data files from the SD memory card installed in the PBX to the connected PC.
This option is only available at Installer level.
The files that can be downloaded from the SD memory card are as follows:
File Name File Type
DSSYS (KX-TDA50)
DSYS (KX-TDA100/KX-TDA200)
DLSYS (KX-TDA600)
System Data
$SYSERR Error Data
$SYSERR1–$SYSERR9
DSKEYSD (KX-TDA50)
DKEYSD (KX-TDA100/KX-TDA200)
DLKEYSD (KX-TDA600)
Feature Access
Downloading the DSYS/DSSYS/DLSYS system data file allows you to make a backup of the configuration of
the PBX.
The error data files are snapshots of the configuration of the PBX taken automatically when a major error
causes a system reset. They can be analyzed by your dealer to identify the source of a problem. If there is
only
one error data file, its name will be $SYSERR. If there is more than one file, the files will be numbered in
chronological order, up to a maximum of 9 files.
To transfer files to the PC
1. From the Utility menu, select File Transfer PBX (SD Card) to PC.
2. Select the file to download from the list of files on the SD memory card.
Only the files listed in the table above can be downloaded. Selecting any other file will cause an error
message to be displayed.
3. Click Transfer.
The Save dialog box will be displayed
Document Version 2010-11 PC Programming Manual 47
