6.1 [4-1-1] Wired Extension—Extension Settings
For each slot in which an extension card is installed, a certain number of extension ports are displayed. For
each extension port, various extension settings can be assigned.
To assign a set of CLIP numbers automatically, click CLIP Generate. To assign names and tenants to
extension
user groups, click Extension User Group Table. See 5.6 [3-2] Extension Group for more details.
Main
Shelf (KX-TDA600 only)
Indicates the shelf position (reference only).
Default
Current shelf number
Value Range
Shelf number
Maintenance Console Location
6.1 [4-1-1] Wired Extension—Extension Settings
Programming Manual References
None
Feature Manual References
None
Slot
Indicates the slot position of each extension card (reference only).
Default
Current slot number
Value Range
Slot number
Maintenance Console Location
6.1 [4-1-1] Wired Extension—Extension Settings
Programming Manual References
3.1 [1-1] Slot
Feature Manual References
None
470 PC Programming Manual Document Version 2010-11
6.1 [4-1-1] Wired Extension—Extension Settings
