3.3 [1-1] Slot—Card Property - MPR
MEC/EMEC card properties can be viewed and set.
Memory Expansion Card:
Indicates
whether an MEC (KX-TDA50/KX-TDA100/KX-TDA200) or EMEC (KX-TDA600) card is mounted on
the MPR (KX-TDA50/KX-TDA100/KX-TDA200) or EMPR (KX-TDA600) card.
To change the EMEC or MEC card installation status, click on this cell, then click OK in the dialog box that
appears. Clicking on the Command button performs the same function. (This operation is only available in
batch mode.)
Removing the EMEC or MEC card here also deletes related EMEC or MEC card data.
Note that when an EMEC or MEC card is installed in the PBX, any SMDR data stored in the PBX is cleared.
Default
Current status
Value Range
None, Installed
Maintenance Console Location
3.3 [1-1] Slot—Card Property - MPR
Installation Manual References
For KX-TDA50:
2.5.7 MEC Card (KX-TDA5105)
For KX-TDA100/KX-TDA200:
2.3.2 MEC Card (KX-TDA0105)
For KX-TDA600:
2.3.2 EMEC Card (KX-TDA6105)
Programming Manual References
None
Feature Manual References
None
Memory Version:
Indicates the hardware version of the
EMEC or MEC card when it is mounted on the EMPR or MPR card
(reference only).
Default
Current version
Value Range
- (not mounted), 1–15
Document Version 2010-11 PC Programming Manual 79
3.3 [1-1] Slot—Card Property - MPR
