2.6 Utility
2.6.1 Utility—Diagnosis
Performs diagnostic tests on cards installed in the PBX, to identify the source of problems.
If any of the tests listed here returns the result "NG" ("No Good"), contact your dealer. Test results can be
saved as a TXT-format (text) file.
When
testing is complete, any cards that were set to OUS status must be returned to INS status if they are to
be used again.
Card Test
Tests the relevant functions of a card to ensure that it is operating correctly. The tests carried out vary according
to the type of card being tested.
The tests that are performed on each card are as follows:
KX-TDA50
Test Type Available Cards
Local loop back diagnosis DHLC4, DLC8, SLC4, SLC8, IP-EXT4, HLC4, PLC4, PLC8, LCOT,
IP-GW4, SIP-GW4
Card CT Bus diagnosis DLC8, SLC8, IP-EXT4, PLC8, IP-GW4
DTMF Receive test port DHLC4, SLC4, SLC8
MSG/SVM Card DTMF receive test MSG2, SVM2, ESVM2
EXT-CID path test EXT-CID
KX-TDA100/KX-TDA200/KX-TDA600
Test Type Available Cards
Local loop back diagnosis DHLC, DLC, SLC8, SLC16, MSLC16, ESLC16, EMSLC16,
CSLC16,
ECSLC24, CSIF, LCOT, ELCOT, T1, PRI, OPB, IP-EXT16
Card CT Bus diagnosis
(KX-TDA100/KX-TDA200 only)
DHLC, DLC, SLC8, SLC16, MSLC16, ESLC16, EMSLC16,
CSLC16,
ECSLC24, CSIF, LCOT, ELCOT, T1, PRI, OPB, IP-EXT16
DTMF Receive test port DHLC, SLC8, SLC16, MSLC16, ESLC16, EMSLC16, CSLC16,
ECSLC24
PT loop back diagnosis DHLC, DLC
Caller ID Card DTMF Sending Out
Diagnosis
SLC8
DSP DTMF generator/receiver
diagnosis
T1
DSP DTMF receiver diagnosis T1
Framer IC alarm signal detection
diagnosis
T1, PRI
Framer IC error detection diagnosis T1, PRI
