Panasonic KX-TDA50

Test Type Available Cards
CS-INF loop back diagnosis CSIF
Super frame synchronization
diagnosis
CSIF
Caller ID card loop back diagnosis LCOT, ELCOT
Extension mode setting test
CTI-LINK loop back diagnosis CTI-LINK
IP-GW
H.323 call simulate diagnosis IP-GW4 (KX-TDA0484), IP-GW16
LAN loop back diagnosis IP-GW4 (KX-TDA0484)
To perform a card test
1. From the Utility menu, select Diagnosis.
2. Click on the Status cell of the card to be tested, and set it to "OUS".
With the KX-TDA50, to perform the EXT-CID path test, set the status of both the EXT-CID card and the
card in slot 1 to "OUS".
3. Click on the cell showing the card type.
A new window will be displayed.
4. Select the Card Test option.
A new window will be displayed.
5. Click Test to perform the test(s).
The error report will be displayed. When all tests are completed, the words "Test End!" will be shown on
the last line of the output.
6. Select an option:
• Click Capture if you want to save the displayed information.
1. Enter a file name, or select a file to overwrite.
2. Click Save.
• Click Cancel to return to the Diagnosis screen.
Pair Port Test (KX-TDA100/KX-TDA200/KX-TDA600 only)
Tests the combination of an extension port and CO line port to ensure that communication with the CO line
port can be carried out successfully.
The pair port test can be carried out using one LCOT or ELCOT card and one DHLC, SLC8, SLC16,
MSLC16, ESLC16, EMSLC16, CSLC16, or ECSLC24 card.
Note
With the
KX-TDA600, the pair of cards to be used for the pair port tests must be installed within the same
shelf.
The tests that are performed are as follows:
Line current OFF (Ext->CO) Line current from extension to CO line turns off.
Line current ON (Ext->CO) Line current from extension to CO line turns on.
Off hook detection (CO->Ext) Off-hook generation/detection from CO line to
extension
Document Version 2010-11 PC Programming Manual 41
2.6.1 Utility—Diagnosis
