3.24 [1-1] Slot—Port Property - IP-Extension Port
Various settings can be programmed for each IP extension port.
To change the status of extension ports, click Command.
IP-PT Registration and De-registration
An IP-PT must be registered to the PBX by programming both the PBX and IP-PT before it can be used.
Programming instructions of the PBX are given below.
It is possible to de-register the IP-PT later.
Preparation
Follow the steps below to prepare before registering an IP
-PT.
1. Open 3.22 [1-1] Slot—Card Property - IP Extension, and confirm that the IP address and subnet mask
settings of the IP-EXT card are correct.
2. Open 3.23 [1-1] Slot—Card Property - IP Extension—Common Settings and set the gateway address.
Registration
Follow the steps below to register the IP-PT.
1. Connect the IP-PT to be registered to the network and, if necessary, the power supply.
2. Click Registration.
A dialog box will appear. Non
-registered (available) extension numbers are displayed on the left.
3. Highlight numbers and click the right arrow to select them for registration. Click Next.
A screen will appear with information on the current IP-PT extension number and index number for
programming.
4. Program the relevant IP-PT.
5. Click Next.
• If the registration is still in process, the dialog box will show "Waiting for IP-PT to register…". Click
OK.
• If the registration is successful, the dialog box will show "Registration Succeed".
If there are more IP-PTs to be registered, click Continue to resume or Cancel to terminate the
registration. If not, click Close.
Once the IP-PT is successfully registered, the status of the IP-PT will update to show "Registered".
De-registration
Follow the steps below to de
-register the IP-PT.
1. Click De-registration.
A dialog box will appear. Registered extension numbers are displayed on the left.
2. Highlight numbers and click the right arrow to select them for de-registration. Click Next.
A dialog box will appear.
3. Click Confirm.
• If the de-registration is successful, the dialog box will show "De-registration Succeed".
• If the de-registration is unsuccessful, the dialog box will show "De-registration Error". De-registration
will be terminated.
4. Click Close.
If the IP-PT is successfully de-registered, the status of the IP-PT will update to show "None".
Document Version 2010-11 PC Programming Manual 197
