Forced De-registration
Follow the steps below to forcibly de
-register the IP-PT when normal de-registration has been unsuccessful
or IP address settings have been changed or deleted only on the IP-PT.
1. Click Forced De-registration.
A dialog box will appear. Registered extension numbers are displayed on the left.
2. Highlight numbers and click the right arrow to select them for forced de-registration. Click Next.
A dialog box will appear.
3. Click OK.
A dialog box will appear.
4. Click Confirm.
If the de-registration is successful, the dialog box will show "Forced De-registration Succeed".
5. Click Close.
Once the IP-PT is successfully de-registered, the status of the IP-PT will update to show "None".
Shelf (KX-TDA600 only)
Indicates the shelf position (reference only).
Default
Current shelf number
Value Range
Shelf number
Maintenance Console Location
3.24 [1-1] Slot—Port Property - IP-Extension Port
Programming Manual References
None
Feature Manual References
None
Slot
Indicates the slot position (reference only).
Default
Current slot number
Value Range
Slot number
Maintenance Console Location
3.24 [1-1] Slot—Port Property - IP-Extension Port
198 PC Programming Manual Document Version 2010-11
3.24 [1-1] Slot—Port Property - IP-Extension Port
