3.5 [1-1] Slot—Port Property - Extension Port
Various settings can be programmed for each extension port.
To change the status of extension ports, click Command. To view total numbers of each type of extension
connected, click Port Type View.
Shelf (KX-TDA600 only)
Indicates the shelf position (reference only).
Default
Current shelf number
Value Range
Shelf number
Maintenance Console Location
3.5 [1-1] Slot—Port Property - Extension Port
Programming Manual References
None
Feature Manual References
None
Slot
Indicates the slot position (reference only).
Default
Current slot number
Value Range
Slot number
Maintenance Console Location
3.5 [1-1] Slot—Port Property - Extension Port
Programming Manual References
None
Feature Manual References
None
Document Version 2010-11 PC Programming Manual 87
3.5 [1-1] Slot—Port Property - Extension Port
