4.20 [2-11-2] Audio Gain—Card
Gain levels can be programmed for each type of card.
Up Gain (To PBX)
Specifies the volume for audio signals from the selected type of card to the PBX.
Default
Depends on card type.
Value Range
-15–15 dB
Maintenance Console Location
4.20 [2-11-2] Audio Gain—Card
Programming Manual References
None
Feature Manual References
None
Down Gain (From PBX)
Specifies the volume for audio signals from the PBX to the selected type of card.
Default
Depends on card type.
Value Range
-15–15 dB
Maintenance Console Location
4.20 [2-11-2] Audio Gain—Card
Programming Manual References
None
Feature Manual References
None
Document Version 2010-11 PC Programming Manual 379
4.20 [2-11-2] Audio Gain—Card
