4.14 [2-8-1] Ring Tone Patterns—Call from CO
Different ring tone patterns can be selected for incoming CO line calls depending on the trunk group that the
calls are received on. A maximum of 8 Ring Tone Pattern Tables can be programmed, and any pattern table
can be selected for use by an extension.
Ring Tone Pattern Plan 1–8
Specifies the ring tone pattern for incoming CO line calls.
Default
Single
Value Range
Single, Double
, Triple
Maintenance Console Location
4.14 [2-8-1] Ring Tone Patterns—Call from CO
Programming Manual References
12.1 [10-1] CO Line Settings—
Trunk Group Number
6.1 [4-1-1] Wired Extension—Extension Settings
—Option 1—
Ring Pattern Table
6.10 [4-2-1] Portable Station—Extension Settings
—Option 1—
Ring Pattern Table
Feature Manual References
15.1.2 Ring Tone Pattern Selection
Document Version 2010-11 PC Programming Manual 333
4.14 [2-8-1] Ring Tone Patterns—Call from CO
