Panasonic KX-TDA50

Item Description
RTP Receive Abandoned Packet Counter Total number of packets abandoned.
RTP Arrive Packet Interval (MAX.) [ms] Maximum time taken for a packet to
arrive.
RTP Arrive Packet Interval (MIN.) [ms] Minimum time taken for a packet to
arrive.
To view IP extension information
1. From the Utility menu, select IP Extension Statistical Information.
2. From the Card Selection drop-down list, select the slot number.
3. Click Execute.
The statistical information will be displayed.
4. Select an option:
• Click Capture if you want to save the displayed information.
1. Enter a file name, or select a file to overwrite.
2. Click Save.
• Click Clear to erase the information and reset the Collection Started Time
.
5. Click Cancel to return to the main screen.
2.6.14 Utility—CS Information
Displays information stored by the PBX regarding each Cell Station (CS).
This option is only available at Installer level, and requires that the target CSIF, DHLC or DLC card be set to
INS status.
For DHLC/DLC cards, only the information for ports that have CSs connected to them is displayed.
The displayed items are as follows:
Item Description
Shelf-Slot Number of the slot (for KX-TDA600, shelf and slot)
Port Number of the port
CS Name Name of the attached CS
Status Service status of the attached CS: INS, OUS, or FAULT.
If the status is FAULT, subsequent data items for that port will be left
blank.
Version Version number of the program file stored in the CS
Revision Revision number of the program file stored in the CS
CSID 12-digit ID number of the CS
Path Number of the wireless extension currently using each path. In the case
of
a group, several extensions may be using the same floating extension
number.
When an extension number is not registered, the display shows
"OFF". The number of paths that can be used varies for each CS model.
For more details, see the documentation for your CS.
54 PC Programming Manual Document Version 2010-11
2.6.14 Utility—CS Information
