Connection Settings for RS-232C
Setting Values Explanation
Port COMx Specify the number of the COM port
assigned to the PC’s RS-232C
interface.
Only available COM ports are
displayed.
Baud Rate (bps) 2400, 4800, 9600, 19200,
38400, 57600, 115200
Specify the speed of data transmission.
Connection Settings for Modem
Setting Values Explanation
Dial Number 1-9,
0, *, #, -, "," [comma], T, P,
W
Enter the telephone number to be dialed
to access the PBX.
T: Converts the Dial Type from Pulse to
Tone.
"," [comma], P, W: Inserts a pause.
Dial Type Auto(Tone), Auto(Pulse),
Manual
Specify the outgoing dialing method.
If Manual is chosen, dialing must be
done with a connected telephone.
Comment Max. 40 characters Enter a comment to identify the set of
values.
Port COMx Specify the number of the COM port
assigned to the PC’s modem interface.
Only available COM ports will be
displayed.
Baud Rate (bps) 1200, 2400, 4800, 9600,
19200, 38400
Specify the speed of data transmission.
Modem Initialize – Enter the modem initialize command,
and click Initialize to send the
command to the modem.
For
more details, refer to your modem’s
instruction manual.
Connection Settings for LAN
Setting Values Explanation
IP Address 1.0.0.0–223.255.255.255 Specify the IP address of the PBX on
the LAN. Enter the same IP address
that was input in IP Address of
3.30 [1-1] Slot—Card Property -
CTILINK (KX-TDA100/KX-TDA200/
KX-TDA600 only).
Document Version 2010-11 PC Programming Manual 17
2.1.1 Starting Maintenance Console and Software Modes
