Panasonic KX-TDA50

To change the status (INS/OUS) of a card (Interactive mode only)
1. Move the mouse pointer over the card.
A menu will be shown under the mouse pointer.
2. Select the desired status:
• Click INS to set the card to in-service status.
• Click OUS to set the card to out-of-service status.
To install an option card on an OPB3 card
1. Move the mouse pointer over the card.
A menu will be shown under the mouse pointer.
2. Select Option Card.
The OPB3
Option Card Setup screen will be displayed. See 3.29 [1-1] Slot—OPB3 Option Card Setup
(KX-TDA100/KX-TDA200/KX-TDA600 only).
Supported Card Types
KX-TDA50
Card
Maximum
Quantity
Supported
Slot Numbers
Card Programming
MPR: Main Processing Card 1 00 3.3 [1-1] Slot—Card
Property - MPR
DHLC4: Pre-installed Super
Hybrid Ports
1 01
3.4 [1-1] Slot—Card Property -
Extension Type
DLC4: 4-Port Digital Extension
Card
1
02–04 (Type A
Slots)
HLC4: 4-Port Hybrid Extension
Card
PLC4: 4-Port Proprietary
Extension Card
SLC4: 4-Port Single Line
Telephone Extension Card
LCOT4:
4-Port Analog Trunk Card 3 3.10 [1-1] Slot—Card Property -
LCO type
DLC8: 8-Port Digital Extension
Card
2
05–07 (Type B
Slots)
3.4 [1-1] Slot—Card Property -
Extension Type
PLC8: 8-Port Proprietary
Extension Card
SLC8: 8-Port Single Line
Telephone Extension Card
IP-GW4: 4-Channel VoIP
Gateway Card
1 3.19 [1-1] Slot—Card Property - IP
Gateway
IP-EXT4: 4-Channel VoIP
Extension Card
1 3.22 [1-1] Slot—Card Property - IP
Extension
SIP-GW4: 4-Channel SIP CO line
Card
1 3.25 [1-1] Slot—Card
Property - SIP
Gateway (KX-TDA50 only)
Document Version 2010-11 PC Programming Manual 71
