Panasonic Lumix S1R User Manual

6. Focus/Zoom
101

Move and Change the Size of the Yellow AF Area
You can move the yellow AF area to the position of the white AF area and
replace the white AF area with the yellow AF area.
If moving to a position outside an AF area, then the [ ] AF area will be
set.
1
Press [ ] to display the AF mode selection screen.
2
Select [ ] and then press 4.
3
Press 3421 to move the position of
the AF area.
4
Rotate or to change the size
of the AF area.
5
Press .
0
On the recording screen, press , or
touch [ ] to cancel the AF area setting.
Operations on the AF area movement screen
Button
operation
Touch
operation
Description of operation
3421 Touch
Moves the AF area
0 Positions can be moved to the diagonal
directions using the joystick.
Pinch out/
pinch in
Enlarges/reduces the AF area in small steps.
s Enlarges/reduces the AF area.
[DISP.] [Reset]
First time: Returns the AF area position to the
centre.
Second time: Returns the AF area size to the
default setting.

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
