6. Focus/Zoom
108
Operations on the AF area movement screen
[Pinpoint]
You can achieve a more precise focus on a
small point.
If you press the shutter button halfway, the
screen that lets you check the focus will be
enlarged.
Button
operation
Touch
operation
Description of operation
3421 Touch
Moves the AF area
0 Positions can be moved to the diagonal
directions using the joystick.
Pinch out/
pinch in
Enlarges/reduces the AF area in small steps.
s Enlarges/reduces the AF area.
[DISP.] [Reset]
First time: Returns the AF area position to the
centre.
Second time: Returns the AF area size to the
default setting.
0 Change the movement speed of a single AF area:
[] ¨ [ ] ¨ [1-Area AF Moving Speed] (l 311)
0 When the focus mode is set to [AFC], [ ] is not available.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix S1R and is the answer not in the manual?

Panasonic Lumix S1R Specifications

General IconGeneral
Sensor Resolution47.3MP
Sensor TypeFull-frame CMOS
ISO Sensitivity100-25600 (expandable to 50-51200)
Image ProcessorVenus Engine
Image Stabilization5-axis in-body image stabilization
Camera TypeMirrorless
Sensor Size36 x 24 mm
Lens MountL-Mount
Shutter Speed1/8000 to 60 sec, Bulb
ConnectivityWi-Fi, Bluetooth
BatteryDMW-BLJ31 Lithium-Ion
Dimensions148.9 x 110.0 x 96.7 mm
Autofocus SystemContrast Detection AF System with DFD Technology
Viewfinder5.76 million dots OLED EVF
LCD Screen3.2-inch, 2.1 million dots, touch screen
Video Recording4K up to 60p
Continuous Shooting9 fps (AFS/MF), 6 fps (AFC)
Weather SealingYes
Memory Card Slots2x SD Card Slots (1x UHS-II Compatible)
