6. Focus/Zoom
117
MF (Manual Focus) refers to manual focusing.
Use this function when you want to fix the focus or when the distance
between the lens and the subject is determined and you do not want to
activate AF.
1
Set the focus mode lever to
[MF].
2
Select the point to be brought
into focus.
≥Tilt the joystick to select the point to
bring into focus.
≥Even by pressing [ ], you can
display the focus position
movement screen.
0
To return the position to be brought into
focus to the centre, press [DISP.].
3
Confirm your selection.
≥Press .
≥This switches to the MF Assist
screen, and shows an enlarged
display.
Record Using MF

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix S1R and is the answer not in the manual?

Panasonic Lumix S1R Specifications

General IconGeneral
Sensor Resolution47.3MP
Sensor TypeFull-frame CMOS
ISO Sensitivity100-25600 (expandable to 50-51200)
Image ProcessorVenus Engine
Image Stabilization5-axis in-body image stabilization
Camera TypeMirrorless
Sensor Size36 x 24 mm
Lens MountL-Mount
Shutter Speed1/8000 to 60 sec, Bulb
ConnectivityWi-Fi, Bluetooth
BatteryDMW-BLJ31 Lithium-Ion
Dimensions148.9 x 110.0 x 96.7 mm
Autofocus SystemContrast Detection AF System with DFD Technology
Viewfinder5.76 million dots OLED EVF
LCD Screen3.2-inch, 2.1 million dots, touch screen
Video Recording4K up to 60p
Continuous Shooting9 fps (AFS/MF), 6 fps (AFC)
Weather SealingYes
Memory Card Slots2x SD Card Slots (1x UHS-II Compatible)
