Panasonic Lumix S1R User Manual

7. Drive/Shutter
141
Picture Selection Operations

Picture Selection Slide View Screen Operations
A Slide bar
B Picture selection slide view
C Position of displayed frame
Button
operation
Touch
operation
Description of operation
21/
Drag/
Selects a frame.
0 To change the frames displayed in the picture
selection slide view, select the frame at the left/
right end and then touch [ ] or [ ].
21
Press and
hold
Touch and hold
Continuously rewinds or forwards frame-by-
frame.
s
Touch/drag
Selects the frame to display.
Pinch out/
pinch in
Enlarges or reduces the display.
s
Selects a frame while maintaining the enlarged
display (during enlarged display).
3421 Drag
Moves the enlarged display position (during
enlarged display).
[] Displays the 6K/4K burst playback screen.

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
