Panasonic Lumix S1R User Manual

14. Menu Guide
351
[Monitor / Display] ¨ ¨
[Power Save Mode]
[Sleep Mode] [10MIN.]/`[5MIN.]/[2MIN.]/[1MIN.]/
[OFF]
[Sleep Mode(Wi-Fi)] `[ON]/[OFF]
[Auto LVF/Monitor
Off]
`[5MIN.]/[2MIN.]/[1MIN.]/[OFF]
[Power Save LVF
Shooting]
[Time to Sleep]
[Method of Activation]
This is a function to automatically turn the camera to sleep
(power save) status or turn off the viewfinder/monitor if no
operation is performed for a set time.
0 For details, refer to page 44.
[Monitor Frame
Rate]
[30fps]/`[60fps]
This sets the monitor frame rate.
[30fps]: Reduces the power consumption, extending the
operating time.
[60fps]: Enables smooth display of movements.
[LVF Frame Rate]
`[60fps]/[120fps]
This sets the viewfinder frame rate.
[60fps]: Reduces the power consumption for a longer
operating time.
[120fps]: Enables smooth display of movements.
0 [LVF120] is displayed on the viewfinder when it is
displayed at [120fps].
0 When the following functions are being used, the camera
displays in [60fps]:
– Video recording
– Playback
– [ ] mode
– [6K/4K PHOTO]
– HDMI output

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
