Panasonic Lumix S1R User Manual

11. Recording Videos
253
External Microphones (Optional)
With a Stereo Shotgun Microphone (DMW-MS2: optional) or Stereo
Microphone (VW-VMS10: optional), you can record higher-quality audio
compared to the built-in microphone.
1
Set the [Mic Socket] that suits the device to be
connected.
≥ ¨ [ ] ¨ [ ] ¨ [Mic Socket]
0
The setting will be fixed to [Mic Input (Plug-in Power)] when a Stereo Shotgun
Microphone (DMW-MS2: optional) is connected.
0 When using [Mic Input (Plug-in Power)], if you connect an external
microphone that does not require power supply, the connected external
microphone may malfunction.
Check the device before connecting.
2
Turn off the camera.
[Mic Input (Plug-
in Power)]
When connecting an external microphone
that requires a power supply from the camera
[MIC] terminal.
[Mic Input]
When connecting an external microphone
that does not require a power supply from the
camera [MIC] terminal.
[Line Input]
When connecting an external audio device
for line output.

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
