Panasonic Lumix S1R User Manual

8. Metering/Exposure/ISO Sensitivity
188
You can check the effects of aperture on the recording screen by physically
closing the aperture blades of the lens to the aperture value set for actual
recording.
In addition to the effects of aperture, you can check the effects of shutter
speed at the same time.
0
Use the Fn button registered with [Preview] to operate. In default settings, this is
registered in [Fn2].
For information about the Fn button, refer to page 278.
Press the preview button.
0 Each press of the button switches between the
effect preview screens.
Preview Mode
Aperture effect: OFF
Shutter speed effect:
OFF
Aperture effect: ON
Shutter speed effect:
OFF
Aperture effect: ON
Shutter speed effect:
ON
0 It is possible to record in preview mode.
0 Range for shutter speed effect check is 8 seconds to 1/16000 of a second.
0 Preview mode is not available when recording with [6K/4K Pre-Burst].

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
