Panasonic Lumix S1R User Manual

8. Metering/Exposure/ISO Sensitivity
185
In [M] mode (Manual Exposure mode), you can take pictures by manually
setting the aperture value and shutter speed.
In default settings, the ISO sensitivity is set to [AUTO].
As a result, the ISO sensitivity will be adjusted according to the aperture
value and shutter speed.
Exposure compensation can also be used when ISO sensitivity is set to
[AUTO].
1
Set the mode dial to [M].
2
Set the aperture value and
shutter speed.
≥Rotate to set the aperture
value, and to set the shutter
speed.
A Aperture value
B Shutter speed
3
Start recording.
0 If the correct exposure is not achieved
when the shutter button is pressed
halfway, the aperture value and the
shutter speed blink red.
Manual Exposure Mode
F5.6303030

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
