Panasonic Lumix S1R User Manual

16. Connecting to Other Devices
441
If you connect the camera to a printer that supports PictBridge, you can
select pictures on the camera’s monitor and then print them.
Getting started:
0 Turn on the camera and printer.
0 Set the print quality and other settings on the printer.
1
Display the playback screen.
≥Press [(].
0
Images are displayed separately by card
slot.
To switch the card to display, after
pressing [ ], press 34 to select
[Card Slot 1(XQD)] or [Card Slot 2(SD)],
and then press or .
0 You can also select the card to be displayed using the Fn button [Card Slot
Change] (l 284).
0 The card for printing cannot be changed after connecting to the printer.
2
Connect the camera and printer with the USB
connection cable (C–C or A–C).
0 Plug in/out straight holding onto the plug.
(Inserting these at an angle may cause deformation or malfunction)
0 Do not connect the cable to the wrong terminals. This may cause a
malfunction.
Printing

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
