Panasonic Lumix S1R User Manual

194
9. White Balance/Image Quality
White balance (WB) is a function that corrects the colour cast produced by
the light illuminating the subject.
It corrects the colours so that white objects appear in white to make the
overall colour closer to what is seen by the eye.
Normally, you can use auto ([AWB], [AWBc] or [AWBw]) to obtain the
optimal white balance.
Set this function when the colouring of the image is different from what you
expected, or you want to change the colouring to capture the ambience.
1
Press [WB].
2
Select the white balance.
≥Rotate , or .
≥Selection is also possible by
pressing [WB].
Setting the White Balance (WB)
1
1
2
2
2
2
2
2
AWBc
AWBc
AWBw
AWBw
WBWBWBWBWBWBWBWBWBWBWB
AWBAWB

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
