Panasonic Lumix S1R User Manual

9. White Balance/Image Quality
197

White Sets ([ ] to [ ])
Take pictures of a white object under the light source of the recording
location to adjust the white balance until it appears white.
1
Press [WB] and then select any value from [ ] to [ ].
2
Press 3.
3
Aim the camera at a white object so that it appears inside the frame at
the centre of the screen and then press or .
0
This will set the white balance and return you to the recording screen.

Colour Temperatures ([ ] to [ ])
Set the numeric value for the white balance colour temperature.
1
Press [WB] and then select any value from [ ] to [ ].
2
Press 3.
0
The colour temperature setting screen is displayed.
3
Press 34 to select the colour temperature and then press or
.
0
You can set the White Balance Bracket (Colour Temperature) by rotating ,
or . (l 160)
Adjusting the White Balance
You can adjust the colouring even when the colouring you want to apply is
not produced by the selected white balance.
1
Press [WB].
0 You can set a colour temperature from [2500K] to [10000K].
1
4
1
4
1
4
1
4

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
